ASUS PRIME H410-MK
Intel® H410 (LGA 1200) mic-ATX motherboard with DDR4 support, DVI, D-Sub, USB 3.2 Gen 1 ports, SATA 6 Gbps, COM header
Product image gallery
About this product
Details & use
Intel® H410 (LGA 1200) mic-ATX motherboard with DDR4 support, DVI, D-Sub, USB 3.2 Gen 1 ports, SATA 6 Gbps, COM header
Technical specifications are provided by Taba Trading Expansion. Products are sold exclusively through authorized dealers. For availability, pricing, and orders, please contact the sales team.
Photo 1/6
Specifications
Technical specs
Motherboard
- Platform
- Intel
- Form factor
- m-ATX
- Chipset
- Intel H410
- Clear CMOS
- Yes
- BIOS
- 128MB Flash ROM, UEFI AMI BIOS
- Operating system
- Windows® 10 64-bit, Windows® 11 64-bit
- Series
- Prime
Processor
- CPU power connector
- یک pcs 8 پین
- CPU generation
- نسل دهم
- Socket
- Intel Core i3/i5/i7/i9 , Pentium Gold and Celeron
- CPU socket
- LGA-1200
Memory
- Memory
- supports memory RAM DDR4 با up to frequency 2933 MHz
- RAM capacity
- 64 GB
- Memory type
- DDR4
- RAM slots
- 2 PCS
Expansion Slots
- PCIe x4
- No
- PCIe x16
- یک slot PCIe 3.0 x16
- PCIe x1
- PCIe 3.0, 2 PCS
Storage
- SATA III
- 4 pcs
- M.2
- No
I/O & Connectivity
- Wi-Fi
- No
- Bluetooth
- No
- Audio channels
- 7.1 کانال
- Audio
- Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC
- LAN
- LAN (RJ45) port
- Thunderbolt
- No
- DisplayPort
- No
- USB 2.0
- 4 pcs
- USB 3.2
- 2 PCS
- USB 3.0
- No
- HDMI
- No
- USB 3.1
- No
- Digital audio
- No
Power
- Power switch
- No
Other specs
- 3.5 mm jack
- 3 pcs
- D-Sub
- Yes
- DVI
- Yes
- Multi-GPU support
- No
- PCI
- No
- Configure
- دو کاناله
- Debug display
- No
- LED color
- No
Key points
Why this product?
The standout features that make this model a strong choice for professional builds.
Wi-Fi: No
Bluetooth: No
3.5 mm jack: 3 pcs
Audio channels: 7.1 کانال
